This is the main reason (amount MANY others) I would not attempt an long distance coastal voyage on a M26, especially on one of the most exposed and remote coast lines in Oz.
Took this at my local club, a M26 chain plate set up.
Issues are, IMHO as a someone who has done a fair bit of yacht rigging, set up a number of yachts from scratch, has 10 years in the industry and more than double that sailing/racing/cruising.
- Why use crimped swages, and if you do why use a hand tool and double swage? If done properly with a hydraulic press there is no need for a second swage, someone is cutting corners and covering their arse here. A minor weak point.
- Standard thimbles. Thimble should be hi-load eg, be a complete loop of have a bar welded across them. You can see these have already started to elongate, causing the wire to turn a sharpers corner than it is designed to. A major weak point.
- The connection between the thimble and the shroud adjuster is a hard point with not much S/S thickness. A major weak point.
- On the chain plate itself there is only two 1/4" bolts holding 2 x 4mm shrouds, seems way under to me.
We rigged up a 5.4m trailer sailor from scratch (built the boat) and our setup was at least twice as strong as this. We also rigged up a Shaw 650 Sports Boat which only weighs 350kg with a 100kg bulb and our setup was 4 times stronger than this.
And this was only looking at the chain plates. The forestay, the backstay and spreader attachments also looked just as weak.
I would be suspicious sailing one of these in a reasonable Freo Doctor seabreeze in cockburn sound, let alone how strong the SE'stly can be at Geraldton.
It's all well and good to have a bit of adventure, but not something I would attempt.....ever.
